| Specification | Minimum | Typical | Maximum |
| Channels | | 2x Transmitters, 4x Receivers | |
| Antennas | | 6x Onboard Patch Antennas | |
| Modulations | | FMCW, CW | |
| Typical Frequency Range | 24GHz | | 25GHz |
| Expandable Frequency Range | 23.5GHz | | 26GHz |
| Sweep Time | | 0.5ms, 1ms, 2ms, 4ms, 8ms | |
| Samples per Sweep | | 128, 256, 512, 1024, 2048, 4096 | |
| Tune Voltage | 0 | | 4V |
| Tuning Sensitivity | | 0.8GHz/V | |
| Transmit Power | 16dBm | 17dBm | 18dBm |
| SSB Phase Noise @1MHz offset | | -99dBc | |
| Noise Figure | | 10dB | |
| Maximum Input Power | | 5dBm | |
| IIP_1dB | | -12dBm | |
| Supply Voltage | 5.75V | 6V | 6.25V |
| Supply Current | | 1200mA | |
| Operating Temperature | -40°C | | 85°C |
| Dimensions | | L:130mm, W:108mm, H:32mm | |
